Solids FIRE PACKAGES
Handling
Solids Diverter Package Sets Prepackaged
Pump Houses
Water INDUSTRY FIRE OIL & GAS FIRE OIL & GAS
cONFIGURAtION cONFIGURAtION cONFIGURAtION
Electric motor drive, tank packages Single or multiple pump package sets, Design and supply of enclosure and
horizontal end suction close and long installation inside of main fire pump sets,
DISchARGE & PERFORmANcE coupled, split case long coupled, multi-stage jockey pump, controllers, starters, all
• 100 mm to 200 mm multi-outlet and vertical turbine all electric internal pipe work, test line, flow meter,
• Outputs up to 75 m3/h motor or engine driven wiring and lighting to provide a fully
• Heads up to 40 m packaged unit.
DISchARGE & PERFORmANcE
FEAtURES • E nd Suction (Single Stage) – 32 mm DISchARGE & PERFORmANcE
• Automatic totally enclosed sewage to 150 mm. Outputs up to 500 m3/h • E nd Suction (Single Stage) – 32 mm
pumping station Heads up to 15.2 bar to 150 mm
• Low noise levels • O utputs up to 230 l/s Heads up to 60 bar • O utputs up to 500 m3/h. Heads up to 15.2 bar
• High efficiency pumping units • S plit Case – 80 mm to 300 mm. • End Suction (multi-stage) – 100 mm
• Minimum maintenance – unique system Heads up to 44.5 bar (Approved fire set) to 125 mm
avoids solids passing through pumps so • Multi-stage multi-outlet – 100mm to • O utputs up to 830 m3/h. Heads up to 60 bar
eliminates blockage 125mm. Outputs up to 315 l/s. Heads up • S plit Case – 80 mm to 300 mm
• 4 sizes of plant available to suit inflow to 60 bar • Outputs up to 9000 m3/h.
conditions • Vertical Turbine – 200 mm to 508 mm Heads up to 44.5 bar
• Suitable for basement installation Outputs up to 9000 m3/h • Vertical Turbine – 200 mm to 508 mm
• Clean and environmentally friendly • M ulti-stage / multi-outlet – 50mm to 250 • O utputs up to 315 l/s. Heads up to 31.1 bar
• Economical to operate mm. Outputs up to 850 m3/h. Heads up to
850m. Up to 140 oC FEAtURES
• Delivered complete, ready for immediate
FEAtURES installation on simple foundations
• Meeting the requirements of worldwide • E ase of site installation and connection
insurance and approvals bodies • Single responsibility for complete
• End Suction – Centreline discharge back pump house
pull-out rotating element can be removed • F ully tested and pre-commissioned using
without disturbing pipe work advanced computerised testing facilities
• End Suction – Close coupled, space and • Individually engineered to customer
cost saving solution requirements
• Axially split case rotating element can be • C ontainerised CAD design
removed without disturbing pipework • W all insulation reduces
• R igid, box-section baseplates for end suction environmental noise
and split case long coupled packages
• S tainless steel shaft with tight tolerances
designed to transmit the maximum load
across full pump curve
• B earing arrangements of ample proportion
• IE2 motors fitted as standard
• Impellers machined and hand finished to
meet customer duty
